Bosch Rexroth PS5000 - List of Parameter Numbers for Direct Selection Mode

4−8 Electric Drives
and Controls
Bosch Rexroth AG BT 6.190 1070087068 / 01
Operation
4.4.1 List of parameter numbers for
direct selection mode
Affected range Description Parameter number
Procedure Basic program (block program 0):
1st derivative−action time 1
Derivative−action time 2
Slope (on/off) 3
Holding time 67
Run inhibit (progr.) 68
Internal ignition (progr.) 69
Block program 1:
Delay
(block delay time; input using BOS as 1st
VHZ in the program)
4
Slope time (current increase time SSZ) 5
Starting performance 6
Velocity in cm/min (see page 4−19) 7
Current/pause % (see page 4−19) 8
Impulses/cm (see page 4−19) 9
Performance (input using BOS as 2nd STZ in
the program)
10
Under−current time (input using BOS as 2nd
STZ in the program)
11
Pause time (input using BOS as 2nd PSZ in
the program)
12
Block program 2:
Delay
(block delay time; input using BOS as 1st
VHZ in the program)
13
Slope time (current increase time SSZ) 14
Starting performance 15
Velocity in cm/min (see page 4−19) 16
Current/pause % (see page 4−19) 17
Impulses/cm (see page 4−19) 18
Performance (input using BOS as 2nd STZ in
the program)
19
Under−current time (input using BOS as 2nd
STZ in the program)
20
Pause time (input using BOS as 2nd PSZ in
the program)
21
Block program 3:
Delay
(block delay time; input using BOS as 1st
VHZ in the program)
22
Slope time (current increase time SSZ) 23
Starting performance 24
Velocity in cm/min (see page 4−19) 25
Current/pause % (see page 4−19) 26
Impulses/cm (see page 4−19) 27
Performance (input using BOS as 2nd STZ in
the program)
28
