Operation
4.5.5 Display data from the last weld
The BT 6.190 can be used to display:
D with which spot seam program thelast weld was carried out
D with which reference and actual currents and which phase angle a
certain program ran last.
L Proceed as follows:
1. Press the
key.
2. Use the
or key to move the cursor to the ”LAST RUN” line.
3. Press the
key.
The cursor is in line 1 (Program).
Line 3 indicates which program ran last.
4. To display the data of the last weld of a certain program, enter the
desired program number in line 1 and press key
.
The BT 6.190 opens a screen containing the reference and actual
currents and the phase angle of the last weld for this program.
Press key
to scroll through the run data of the block programs.
5. To display the data of additional spot seam programs:
Press the key until the text ”Program” is displayed in the first line.
Continue with 4.
To return to the main menu: press the
key.
. You can also use function key F3 to open sublevel LAST RUN
(steps 1. to 3.).
