4−12 Electric Drives
and Controls
Bosch Rexroth AG BT 6.190 1070087068 / 01
Operation
Affected range Parameter numberDescription
Setup of SST Display SST type 133
Internal ignition (S)
Range of values: ON/OFF
134
Run inhibit (S).
Range of values: ON/OFF
135
Clear memory (reset all welding parameters
to default values and delete all item alloca-
tions)
136
FK for error.
Range of values: ON/OFF
137
FK duration.
Range of values: 0.0 to 1000.0 ms.
Step size: 0.5
138
FK start.
Range of values: −999.5 to 1000.0 ms.
Step size: 0.5
139
Pressure outlet operating mode
Input: 0−10V, 0−20mA, 4−20mA
140
Welding transformer selection.
Input: PSG... or third−party transformer
141
Number of welding transformers.
Range of values: 0 to 8
142
Welding transformer transmission ratio.
Range of values: 20 to 200
143
Max. transformer secondary current.
Range of values: 5 to 80 kA
144
Performance limit.
Range of values: −15.00 to 100.00
145
Perf. prelim. warning.
Range of values: −15.00 to ”performance
limit”.
146
Maximum programmable current.
Range of values: dep. on PSI
147
Maximum programmable pressure val.
Range of values: 0.00 to 10.00
148
Conversion factor (kN/V).
Range of values: 0.000 to 5.000 kN/V
149
Zero offset.
Range of values: −10.00 to 10.00
150
Maximum programm. under−current time.
Range of values: 1 to 2000 ms
151
Monitor inhibit.
Range of values: ON/OFF
152
Exit time.
Range of values: 0.0 to ”maximum programm.
under−current time”
153
Overlap.
Range of values: ON/OFF
154
Max. permitted performance corr.
Range of values: +: 0.00 to 20.0%
−: −20.0 to 0.00%
155
Max. permitted pressure corr.
Range of values: +: 0.00 to 20.0%
−: −20.0 to 0.00%
156
Setup of BT Display BT6 type 157
LCD contrast 158
Language selection 159
