de Set up and connect
4.5 Remove the transport
struts
4th Remove the transport strut.
1. Loosen and remove the screws of
the vertical transport struts with
a T20 screwdriver.
4.6 Connect the device
Water inlet hose
connect
2. Remove the transport struts.
WARNING
Risk of electric shock!
The device contains live parts.
Touching live parts is dangerous.
▶
Do not immerse the electric
Aquastop valve in water.
Notice: Make sure that you connect
the device to a water inlet with a
safety device against drinking water
contamination through backflow
(according to DIN EN 1717). The
connection valves / taps provided for
this purpose are equipped with this
safety device if the building is
properly installed.
3. Loosen and remove the screws of
the horizontal transport strut with a
T20 screwdriver.
16
