Set up and connect de
1. Connect the water inlet hose to the
tap (26.4 mm = 3/4 ").
sink The water drainage
running hose with
a bend
fix and
to cherish.
Plastic pipe
with rubber sleeve
or gully
The water drainage
running hose with
a bend
fix and
to cherish.
2. Carefully open the tap and check
whether the connection points are
tight.
4.7 Align the device
Connection types water drain
To reduce noise and vibrations and to
prevent the device from wandering,
orientate the device correctly.
1. Loosen the lock nuts clockwise
with an SW17 wrench.
The information will help you to
connect this device to the water outlet.
CAUTION!
When pumping out, the water drainage
hose is under pressure and can become
detached from the installed connection
point.
▶
Secure the water drainage hose
against unintentional loosening.
Notice: Note the pumping heights.
The maximum pumping head is 1
The connecting
pose with a
Hose clamp
(24-40 mm) si-
to cherish.
17th
