15. -Vs (Power)
14. OUT
13. +Vs (Power)
12. N.C.
11. N.C.
10. MUTE
9. STAND-BY
8. -VS (Signal)
7. +VS (Signal)
6. Bootstrap
5. N.C.
4. SVR
3. Non-Inverting Input
2. Inverting Input
1. Stand-by Gnd.
MUTE
STANDBY
THERMAL
SHUTDOWN
SHORT-
CIRCUIT
PROTECTION
TDA7294
-
+
2
7
13
14
6
15
81
9
10
4
3
BOOT-
STRAP
OUT
+Vs (signal)
IN-
IN+
IN+MUTE
MUTE
STANDBY
STANDY
GROUND
-Vs (signal)
TOP-VIEW
+Vs (power)
-Vs (power)
Pin Function
Bose
®
P/N: 170156, TDA7294
DEVICE PIN-OUT DIAGRAMS
