AMPLIFIER PCB ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description Part Number Note
R789 200K, 1206, 1/8W, 1% 124894-2003
R790 16.5K, 1206, 1/8W, 1% 124894-1652
R791 1 MEG, 1206, 1/8W, 5% 124895-1055
R792 1.0K, 1206, 1/8W, 5% 124895-1025
R793 4.22K, 1206, 1/8W, 1% 124894-4221
R794 301 OHM, 1206, 1/8W, 1% 124894-3010
R795 1.0K, 1206, 1/8W, 5% 124895-1025
R796 100K, 1206, 1/8W, 5% 124895-1045
R797 2.49K, 1206, 1/8W, 1% 124894-2491
R798 3.65K, 1206, 1/8W, 1% 124894-3651
R799 432 OHM, 0805, 1/10W, 1% 133625-4320
R800 432 OHM, 0805, 1/10W, 1% 133625-4320
R801 3.65K, 1206, 1/8W, 1% 124894-3651
R802 3.65K, 0805, 1/10W, 1% 133625-3651
R803 1K, 2512, 1W, 5% 181895-1001 3
R804 3.65K, 0805, 1/10W, 1% 133625-3651
R805 3.65K, 0805, 1/10W, 1% 133625-3651
R806 3.65K, 0805, 1/10W, 1% 133625-3651
R807 3.65K, 0805, 1/10W, 1% 133625-3651
R808 10.0K, 1206, 1/8W, 5% 124895-1035
R809 49.9K, 0805, 1/10W, 1% 133625-4992
R810 49.9K, 0805, 1/10W, 1% 133625-4992
R812 100K, 1206, 1/8W, 5% 124895-1045
R813 30K, 0805, 1/10W, 5% 133626-3035
R814 30K, 0805, 1/10W, 5% 133626-3035
R815 30K, 0805, 1/10W, 5% 133626-3035
R816 30K, 0805, 1/10W, 5% 133626-3035
R817 30K, 0805, 1/10W, 5% 133626-3035
R818 30K, 0805, 1/10W, 5% 133626-3035
R819 30K, 0805, 1/10W, 5% 133626-3035
R820 30K, 0805, 1/10W, 5% 133626-3035
R821 100K, 1206, 1/8W, 5% 124895-1045
R822 0.062 OHM, 2512, 1W, 5% 149322-062 3
R823 1 MEG, 0805, 1/10W, 5% 133626-1055
R824 100K, 0805, 1/10W, 1% 133625-1003
R825 2K, 0805, 1/10W, 5% 133626-2025
R826 2K, 0805, 1/10W, 5% 133626-2025
R827 2K, 0805, 1/10W, 5% 133626-2025
R828 274K, 1206, 1/8W, 1% 124894-2743
R900 332 OHM, 1206, 1/8W, 1% 124894-3320
R901 332 OHM, 1206, 1/8W, 1% 124894-3320
R903 332 OHM, 1206, 1/8W, 1% 124894-3320
R904 332 OHM, 1206, 1/8W, 1% 124894-3320
R905 332 OHM, 1206, 1/8W, 1% 124894-3320
