AMPLIFIER PCB ELECTRICAL PART LIST
Capacitors
Reference
Designator
Description Part Number Note
C700 .01uF, 0805, X7R, 50V, 10% 133623-103
C701 .01uF, 0805, X7R, 50V, 10% 133623-103
C702 1uF, ALUM EL, SM, 85C, 50V, 20% 177902-010H
C703 .01uF, 0805, X7R, 50V, 10% 133623-103
C704 1uF, ALUM EL, SM, 85C, 50V, 20% 177902-010H
C705 10uF, ALUM EL, SM, 85C, 25V, 20% 177902-100E
C706 10uF, ALUM EL, SM, 85C, 16V, 20% 177902-100C
C707 .47uF, ALUM EL, SM, 85C, 50V, 20% 177902-R47H
C708 10uF, ALUM EL, SM, 85C, 16V, 20% 177902-100C
C709 .47uF, ALUM EL, SM, 85C, 50V, 20% 177902-R47H
C710 10uF, ALUM EL, SM, 85C, 16V, 20% 177902-100C
C711 10uF, ALUM EL, SM, 85C, 25V, 20% 177902-100E
C712 10uF, ALUM EL, SM, 85C, 25V, 20% 177902-100E
C713 1uF, ALUM EL, SM, 85C, 50V, 20% 177902-010H
C714 .47uF, ALUM EL, SM, 85C, 50V, 20% 177902-R47H
C715 10uF, ALUM EL, SM, 85C, 16V, 20% 177902-100C
C716 10uF, ALUM EL, SM, 85C, 25V, 20% 177902-100E
C717 1uF, ALUM EL, SM, 85C, 50V, 20% 177902-010H
C718 10uF, ALUM EL, SM, 85C, 16V, 20% 177902-100C
C719 .47uF, ALUM EL, SM, 85C, 50V, 20% 177902-R47H
C720 1uF, ALUM EL, SM, 85C, 50V, 20% 177902-010H
C721 10uF, ALUM EL, SM, 85C, 25V, 20% 177902-100E
C722 10uF, ALUM EL, SM, 85C, 16V, 20% 177902-100C
C723 .47uF, ALUM EL, SM, 85C, 50V, 20% 177902-R47H
C724 47uF, EL, BP, 85C, 16V, 20% 147522-470
C725 100uF, ALUM EL, SM, 85C, 16V, 20% 177902-101C
C726 0.1uF, 1206, X7R, 50V, 10% 124957-104
C727 1uF, ALUM EL, SM, 85C, 50V, 20% 177902-010H
C730 4700uF, EL, 105C, 50V, 20%, SNAP-IN 187394
C731 2200uF, EL, 85C, 25V, 20% 185929-222E
C732 2200uF, EL, 85C, 25V, 20% 185929-222E
C733 0.1uF, 1206, X7R, 50V, 10% 124957-104
C734 1000pF, 1206, COG, 50V, 10% 124956-1022
C735 1000pF, 1206, COG, 50V, 10% 124956-1022
C736 0.1uF, 1206, X7R, 50V, 10% 124957-104
C737 1000pF, 1206, COG, 50V, 10% 124956-1022
C738 1000pF, 1206, COG, 50V, 10% 124956-1022
C739 1000pF, 1206, COG, 50V, 10% 124956-1022
C740 1000pF, 1206, COG, 50V, 10% 124956-1022
C741 .01uF, 1206, X7R, 25V, 5% 131754-103
