AMPLIFIER PCB ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator
Description Part Number Note
C748 1000pF, 1206, COG, 50V, 10% 124956-1022
C749 1000pF, 1206, COG, 50V, 10% 124956-1022
C750 1000pF, 1206, COG, 50V, 10% 124956-1022
C751 .01uF, 1206, X7R, 25V, 5% 131754-103
C752 .01uF, 1206, X7R, 25V, 5% 131754-103
C753 3300pF, 1206, X7R, 50V, 10% 124957-332
C754 1000pF, 1206, COG, 50V, 10% 124956-1022
C755 1000pF, 1206, COG, 50V, 10% 124956-1022
C756 1000pF, 1206, COG, 50V, 10% 124956-1022
C757 1000pF, 1206, COG, 50V, 10% 124956-1022
C758 .01uF, 1206, X7R, 25V, 5% 131754-103
C759 270pF, 1206, COG, 50V, 10% 124956-2712
C760 .10uF, 0805, X7R, 50V, 10% 133624
C761 0.1uF, 1206, X7R, 50V, 10% 124957-104
C762 1uF, 1206, X7R, 16V, 10% 181998-105
C763 .10uF, 0805, X7R, 50V, 10% 133624
C764 0.1uF, 1206, X7R, 50V, 10% 124957-104
C765 1uF, 1206, X7R, 16V, 10% 181998-105
C766 3300pF, 1206, X7R, 50V, 10% 124957-332
C767 .10uF, 0805, X7R, 50V, 10% 133624
C768 .10uF, 0805, X7R, 50V, 10% 133624
C770 0.1uF, 1206, X7R, 50V, 10% 124957-104
C771 1uF, 1206, X7R, 16V, 10% 181998-105
C772 0.1uF, 1206, X7R, 50V, 10% 124957-104
C773 0.1uF, 1206, X7R, 50V, 10% 124957-104
C774 0.1uF, 1206, X7R, 50V, 10% 124957-104
C775 0.1uF, 1206, X7R, 50V, 10% 124957-104
C776 0.1uF, 1206, X7R, 50V, 10% 124957-104
C777 0.1uF, 1206, X7R, 50V, 10% 124957-104
C778 0.1uF, 1206, X7R, 50V, 10% 124957-104
C779 0.1uF, 1206, X7R, 50V, 10% 124957-104
C780 2200uF, EL, 85C, 25V, 20% 185929-222E
C781 2200uF, EL, 85C, 25V, 20% 185929-222E
C790 1uF, 1206, X7R, 16V, 10% 181998-105
C791 4700uF, EL, 105C, 50V, 20%, SNAP-IN 187394
C792 .01uF, 0805, X7R, 50V, 10% 133623-103
