AMPLIFIER PCB ELECTRICAL PART LIST
Diodes
Transistors
Reference
Designator
Description Part Number Note
B700 RECTIFIER, BRIDGE, 100V, 6A 187611
B701 RECTIFIER, BRIDGE, 100V, 6A 187611
D701 ZENER, 5.6V, 225MW, 1N5232 135247-5232
D702 DUAL, SOT-23, BAV99 147239
D703 ZENER, 5.6V, 225MW, 1N5232 135247-5232
D704 1N5402 170219
D705 DUAL, SOT-23, BAV99 147239
D706 1N5402 170219
D707 1N5402 170219
D708 ZENER, 5.6V, 225MW, 1N5232 135247-5232
D709 ZENER, 5.6V, 225MW, 1N5232 135247-5232
D710 1N5402 170219
D711 1N5402 170219
D712 1N5402 170219
D715 DUAL, SOT-23, BAV99 147239
D716 DUAL, SOT-23, BAV99 147239
D718 DUAL, SOT-23, BAV99 147239
D719 DUAL, SOT-23, BAV99 147239
D720 DUAL, SOT-23, BAV99 147239
D721 DUAL, SOT-23, BAV99 147239
D722 DUAL, SOT-23, BAV99 147239
D723 DUAL, SOT-23, BAV99 147239
D724 ZENER, 5.6V, 225MW, 1N5232 135247-5232
Reference
Designator
Description Part Number Note
Q700 DARL, P, TIP 147T 172285
Q701 PNP, 55V, 150mA, SOT-23 134743
Q702 NPN, SOT-23, 2SC2812 134741
Q703 NPN, SOT-23, 2SC2812 134741
Q704 PNP, 55V, 150mA, SOT-23 134743
Q705 DARL, P, TIP 147T 172285
Q706 DARL, N, TIP142T 172284
Q707 PNP, 55V, 150mA, SOT-23 134743
Q708 NPN, SOT-23, 2SC2812 134741
Q709 DARL, N, TIP142T 172284
Q710 NPN, SOT-23, 2SC2812 134741
Q711 PNP, 55V, 150mA, SOT-23 134743
Q712 NPN, SOT-23, 2SC2812 134741
Q713 NPN, SOT-23, 2SC2812 134741
Q714 NPN, SOT-23, 2SC2812 134741
Q715 DARL, P, 80V, 25A, SGSD200 197594
Q716 PNP, 2SB560F 140349
Q717 PNP, 55V, 150mA, SOT-23 134743
Q718 DARL, P, 80V, 25A, SGSD200 197594
