Bose L1 Compact - Page 34

34
Electrical Part List
Capacitors (continued)
Power Amplifier PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
C63 0.1uF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C64 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C65 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C66 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C67 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C68 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C69 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+J-BD 4
C70 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+P-AC 4
C71 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C72 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C73 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C74 220pF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C75 220pF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C76 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C77 0.47uF, CC, 25V, 5%, 0805, 1.25X2 150E-474J+J-BD 4
C78 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C80 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C81 220pF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C82 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+P-AC 4
C83 1000pF, CC, 250V, 5%, 0805 150R-102J+J-BD 4
C85 1000pF, CC, 250V, 5%, 0805 150R-102J+J-BD 4
C86 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C87 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C88 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+P-AC 4
C89 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+P-AC 4
C90 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+P-AC 4
C91 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C92 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C93 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C94 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C95 0.1uF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C96 0.1uF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C97 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C98 1uF, CC, 50V, 10%, 0805 150F-105K+J-BD 4
C99 1uF, CC, 50V, 10%, 0805 150F-105K+J-BD 4
C100 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C101 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+P-AC 4
C102 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C103 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C104 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+P-AC 4
C105 220pF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C106 220pF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C107 1uF, CC, 50V, 10%, 0805 150F-105K+J-BD 4
C108 1uF, CC, 50V, 10%, 0805 150F-105K+J-BD 4
C109 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C110 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+P-AC 4
