Bose L1 Compact Service Manual

35
Electrical Part List
Capacitors (continued)
Power Amplifier PCB Assembly
Inductors
Reference
Designator
Description Vendor Part
Number
Note
XYC1 680pF, CC, 400V, 10%, RL, 10X8 150T-681K+5-SO 4
XYC3 680pF, CC, 400V, 10%, RL, 10X8 150T-681K+5-SO 4
XYC5 1000pF, CC, 400V, 20%, RL, Y5, U, 9.5X8,
AH09E102MLO
150T-102M+5-RO 4
YC6 1000pF, CC, 400V, 20%, RL, Y5, U, 9.5X8,
AH09E102MLO
150T-102M+5-RO 4
YC7 1000pF, CC, 400V, 20%, RL, Y5, U, 9.5X8,
AH09E102MLO
150T-102M+5-RO 4
Reference
Designator
Description Vendor Part
Number
Note
L1 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L2 CHOKE-COMMON MODE, 10MH MIN, AC,
240V, 2A, AL
1806-4037+0000 3, 4
L3 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L4 CHOKE-COMMON MODE, 10MH MIN, AC,
240V, 2A, AL
1806-4037+0000 3, 4
L5 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L6 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L7 CHOKE-COMMON MODE, 2X16UH, 8A, FT50-
43
1806-3913+0 4
L8 WIRE JUMPER, ROLLER FORM, D=0.6MM 635N-0002+0 4
L10 WIRE JUMPER, ROLLER FORM, D=0.6MM 635N-0002+0 4
L11 WIRE JUMPER, ROLLER FORM, D=0.6MM 635N-0002+0 4
L12 WIRE JUMPER, ROLLER FORM, D=0.6MM 635N-0002+0 4
L13 CHOKE-COMMON MODE, 2X16UH, 8A, FT50-
43
1806-3913+0 4
L14 FERRITE COIL, 22uH, 20%, BL19.2 1807-220M+9 4
L15 FERRITE COIL, 22uH, 20%, BL19.2 1807-220M+9 4
L19 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L21 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L22 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L23 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L24 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L25 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L26 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L27 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
