3.3. Activation and alarm signals in monopolar and
bipolar mode
The activation and alarm signals are output at volume level 1. The
minimum volume is level 1. The volume of the activation signal should be
increased as necessary for use in relativey noisy surrouondings. The
maximum volume is level 10. The alarm tone is not adjustable.
Mode
Indicator in
menu program
Frequency (Hz)
Signal type
Monopolar Cut
Sound Level 1
500
Continuous sound
Monopolar Coag
Sound Level 2
420
Continuous sound
Bipolar Coag
Sound Level 3
340
Continuous sound
Sim Coag
–
800
Continuous sound
GastroCut end
–
–
Pulsating
alternating sound
Alarm
–
1000
Intermittent
Pos: 18 /679-BOW A/HF-Geräte/ ARC 200/250/3 00e/3 Fun ktionsweise/Not-Aus @ 4\mod_12 70107171492_6.d oc @ 38127 @ 2
3.4. Emergency shutoff
The HF device can be switched off at any time by using on/off switch 27
for emergency shutoff.
Pos: 19 /679-BOW A/HF-Geräte/ ARC 300/350/3 F unktionsweis e/Überwachungsf unktionen @ 5\mod_128 6445166792_6. doc @ 44489 @ 2 33
3.5. Monitoring functions
3.5.1. Self-test
When the HF device is switched on, it runs a self-test that checks the
operating elements, acoustic signal, microprocessor and hardware for
proper operation. If errors occur, see section Detecting and correcting
faults, page 51.
3.5.2. Cyclical test during operation
During operation, safety-relevant functions and signals are tested
cyclically. If errors are detected, the HF generator will shut itself off. An
error message appears on the display. For further information, see
section Detecting and correcting faults, page 51.
