6 Operation
44 Operating Manual ARC 250 / 303 900-301_IFU-V2.2_11316-S0-20131023-EN
Pos: 48 /679-BOW A/HF-Geräte/ ARC 200/250/3 00e/6 Bedienung/ Programm 7 "GastroCUT Pa p" (nur mit Opti on GastroCUT) @ 6\mod_1 29707256371 5_6.doc @ 4810 4 @ 3
6.3.8. Program 7 "Gastro KNIFE" (only with GastroCut option)
This program is used in gastroenterology. Papillotomes and endoscopic
resection instruments are used for cutting and coagulation.
ARC control technology generates the cutting effect with simultaneously
minimized output power.
ARC control facilitates immediate cutting and prevents adhesion of the
electrodes.
Three modes are available in this program:
fast (approximately 2.5 cutting pulses per second),
medium (approximately 1.8 cutting pulses per second) and
slow (approximately 1.4 cutting pulses per second).
For more information on "GastroCut" mode, see section "GastroCut"
mode, page 27.
The key/display "Monopolar Output" 30 is preconfigured.
1. Connect the papillotome to the socket for "Monopolar Output" 30
(use an adapter if necessary).
2. Connect the foot switch to the HF device.
3. Activate the HF current via the yellow key of the foot switch for
cutting.
– or –
Activate the HF current via the blue key of the foot switch for
coagulation.
4. Set the coagulation level using the keys for scabbing level 5/6.
5. Press keys 3 and 4 to switch between:
slow "Gastro KNIFE" (non-accelerated),
dynamic " Gastro KNIFE" (medium speed; default) and
fast dynamic " Gastro KNIFE" (accelerated).
6. In the case of hemorrhages:
Press the key/display for "Forced Coagulation" current 13 or use a
clip.
7. If necessary, remove the papillotome and connect the argon probe
and the ARC PLUS argon unit.
8. Press the key/display for "Spray Coagulation" current" 14.
9. Press the blue key of the foot switch for coagulation.
Pos: 49 /679-BOW A/HF-Geräte/ ARC 200/250/3 00e/6 Bedienung/M enü-Progra mme @ 5\mo d_12701095015 23_6.doc @ 38 535 @ 23
