13 EMC
900-301_IFU-V2.2_11316-S0-20131023-EN Operating Manual ARC 250 / 303 87
Electromagnetic resistance to interference (IEC 60601-1-2, Table 202)
The ARC 250 and ARC 303 are intended to be used in the electromagnetic environment described below.
The customer or user of the ARC 250 and ARC 303 should ensure that these devices are operated in such an
environment.
Tests for resistance to
interference
Tests for resistance to
interference
Tests for resistance to
interference
Tests for resistance to
interference
Electrostatic discharge
(ESD) according to
IEC 61000-4-2
± 6 KV contact discharge
± 6 KV contact discharge
Floors should be made of
wood or cement or covered
with ceramic tiles. If the
floor is covered with
synthetic material, the
relative humidity must be at
least 30 %.
± 8 KV air discharge
± 8 KV air discharge
Fast transient electrical
interference (bursts as per
IEC 61000-4-4
± 2 kV for power supply
lines
± 2 kV for power supply
lines
The quality of the mains
power should correspond
to that of a typical business
or hospital environment.
± 1 kV for input and output
lines
± 1 kV for input and output
lines
Surges as per
IEC 61000-4-5
± 1 kV voltage outer
conductor-outer conductor
± 1 kV voltage outer
conductor-outer conductor
The quality of the mains
power should correspond
to that of a typical business
or hospital environment.
± 2 kV voltage outer
conductor to ground
± 2 kV voltage outer
conductor to ground
Voltage collapses, brief
interruptions and
fluctuations in the power
supply as per
IEC 61000-4-11
< 5 % UT for ½ period
(> 95 % collapse)
40 % UT for 5 periods
(60 % collapse)
70 % UT for 25 periods
(30 % collapse)
< 5 % UT for 5 s
(> 95 % collapse)
< 5 % U
T
for ½ period
(> 95 % collapse)
40 % U
T
for 5 periods
(60 % collapse)
70 % U
T
for 25 periods
(30 % collapse)
< 5 % U
T
for 5 s
(> 95 % collapse)
The quality of the mains
power should correspond
to that of a typical business
or hospital environment. If
the user of the ARC 200,
ARC 250, ARC 300e and
ARC 303 requires it to
continue operating even in
the event of mains power
dropout, it is recommended
to use an uninterruptable
power source or battery to
supply power the ARC 250
and ARC 303.
Note: U
T
is the AC supply voltage prior to the application of the test level.
