Pre Start Inspection and Operation
3.25
12. Make sure that the hydraulic hoses are routed so that they will not be in the way
or damaged during machine operation. Figure 3–37 shows how the hoses might
be routed to keep them out of the way during operation and prevent them from
being damaged.
Figure 3-37 Attachment Hydraulic Hose Routing (shown without hose covers)
13. The attachment is now ready to use.
Before starting the engine, make sure that the Auxiliary Hydraulic control lever is in the
NEUTRAL position. If this control is left in either the forward or reverse position and
the engine is started, the attachment will begin to function.
CAUTION
High Flow
Pressure Relief
Buttons
