Table 4. Permissible Label Dimensions
1-6-3 Transfer Ribbons
Select transfer ribbons which are only a little wider than the labels:
• If a ribbon is too narrow, the printhead comes into contact with the labels wear
• If a ribbon is too wide, there is a risk of wrinkling _ print image errors
Detection of the transfer ribbon occurs via checking the rotation of the transfer ribbon
supply hub. To print all labels up to the end of the transfer ribbon cleanly, the trailer tape
may not be longer than 60 mm. It must be possible to easily remove the end of the transfer
ribbon from the cardboard core.
Dim. Designation Dimensions in [mm]
A Label width Label width in peel-off mode 4–116 25–116
B
Width of liner or endless medium With a medium thickness of
E = 0.07 – 0.25 With a medium thickness of E = 0.25 – 0.35
25–120 10–120
C
Label height Minimum label height Minimum label height in
peel-off mode Maximum label height with printhead 203 dpi
Maximum label height with printhead 300 dpi Maximum label
height with printhead 600 dpi
5 12 2000 2000 1000
D Label gap 2–1000
E Label thickness 0.07–0.35
F Liner thickness 0.07–0.35
G Distance from 1st heating point to edge of liner 2
H Distance from label sensor to edge of liner 5–53
I Width of perforation mark >5
K Height of perforation mark 2–10
L Width of reflex mark >5
M Height of reflex mark 2–10
