Edition 06/10 User Manual 37
BP-PR PLUS Series
5-4 Font List
The Font list function prints the most important parameters of the fonts available in the
printer in tabular form. The table contains both the original fonts in the printer and other
fonts loaded into the printer. The printout occurs using the heat level and print speed
specified in the Setup > Print param. menu.
1. Insert printable medium (labels, endless paper) which extends across the entire
printing width.
2. If the printout is to occur using thermal transfer printing, insert transfer ribbon with
the maximum width.
3. Press the menu button.
4. Select Test > Font list menu.
5. Start printout with the button.
You can cancel the printout with the cancel button.
Figure 14. Font list
The parameters have the following meaning:
Table 17. Parameters of the Font list
i
The printout occurs without taking the label gaps into consideration. This is why
endless media are most suitable for this purpose.
Column Meaning
No. ID number of the font required for programming (command T).
Name Name with which the font is saved internally.
Type
Type of font generation. It provides information on the variability of the font
and is important when programming (command T).
Description
Explanations of the font: size, font family. The printout occurs in the
appropriate font.
