Brady BP-PR 300 PLUS Series User Manual

16 User Manual Edition 04/10
BP-PR PLUS Series
Table 6. Menu structure
3-2 Navigating the Offline Menu
You can control all settings and functions in the offline menu with the navigator pad.
1st menu level 2nd menu level Access
Service Firmware upd.
PIN protection possible
Firmw. fr. card
PIN protection possible
Clr. service ctr.
Only with service key inserted
Adj. gap sensor
Only with service key inserted
Save settings
Only with memory card inserted, PIN
protection possible
Load settings
Only with memory card inserted, PIN
protection possible
OEM Name
Only with service key inserted
Cleaning interval
Only with service key inserted
Figure 6. Navigator Pad
 Press the menu button to switch from Ready mode to the
offline menu.
 Press the  or  button to select menu items on a menu
level or to select values on the parameter level.
 Press the  button on the top menu level several times, if
necessary, to switch from the offline menu to Ready
mode.
 Press the  or  button to reach a higher or lower menu
level or to set values on the parameter level.
 Press the button briefly to enable value selection on the
parameter level, accept a selected value or start a
function.
 Press and hold (> 2 sec.) the button to exit the
parameter level without accepting the parameter setting.
i
You can also make all settings in the offline menu via the Ethernet interface (see 2-
2 Connecting Printer via Ethernet Interface on page 12) or via direct control
commands (see “Programming Manual“).
