Edition 06/10 User Manual 19
BP-PR PLUS Series
4-1-3 Printing Parameters
1. Press the menu button.
2. Select Setup > Print param.
Parameter Meaning Default
Heat Level
Heating value for compensating for differing thermal behavior of
print-heads. Changing this value is then necessary if printing
intensity has changed after replacing printhead. To adapt printing
intensity when using different media, print speeds or printing
contents, you should change the heat level in the software. The
settings from the Print param. menu and the software are added
together. The heat level setting also affects the test printouts.
0
Print Speed
Basic print speed setting. You can re-specify the print speed for
each print job via software. The basic setting is not changed by
this. The print speed setting also affects the test printouts.
100 mm/s
Transfer Print
On for thermal transfer printing: Sensor for monitoring the transfer
ribbon is activated. Off for thermal direct printing: Sensor for
monitoring the transfer ribbon is not activated. You can overwrite
the setting for each print job via software.
On
Warn Level
Ribbon
Warning via the Ethernet interface by way of an SNMP message
or e-mail sent when the remaining diameter of the ribbon supply
roll undershoots the set value (32–74 mm).
Off
Label Sensor
Method for detecting the starting end of the label. Gap Sensor:
Detection using changes in the transparency between the label
and label gap. Bottom-Reflect: Detection using reflex marks on
the bottom of the medium. Continous media: Synchronization of
the paper flow when using endless media in cutting mode. More
detailed information is found in the documentation of the cutter.
GapSensor
Tear-off Mode
Positioning the label medium for tearing off at the tear-off plate.
On: Additional advancement of the label medium which positions
the label gap after the last printed label at the dispense plate.
Off: Label advance stops once the last label has fully passed the
print line.
Off
