Edition 06/10 User Manual 35
BP-PR PLUS Series
5-3 Status Print
The Status print function prints a test image containing information on the configuration
and status of the printer. The printout occurs using the heat level and print speed
specified in the Setup > Print param. menu.
1. Insert printable medium (labels, endless paper) which extends across the entire
printing width. If the printout is to occur using thermal transfer printing, insert
transfer ribbon with the maximum width.
2. Press the menu button.
3. Select Test > Status print menu.
4. Start printout with the button. You can cancel the printout with the cancel
button.
Figure 13. Status print
i
The printout occurs without taking the label gaps into consideration. This is why
endless media are most suitable for this purpose.
