The webpage provides:
Summary of current IP and Serial Port Settings (available on Home Page)
Separate pages to configure each serial port.
Serial Port Settings:
o Baudrate (Maximum 1M baud)
o Databits (8, 7, 6, 5)
o Stopbits (1, 2)
o Parity (None, Even, Odd, Mark, Space)
o Handshaking (RTS/CTS, DTR/DSR, Xon/Xoff)
o Duplex Mode (Full Duplex, Half Duplex)
For details of Full Duplex and Half Duplex communications, see Section 6
Networking Protocol settings for each Serial Port:
NB: If you are using the Brainboxes Windows driver to create a COM port then the
driver will use Telnet + COM port Control Mode (Server) regardless of the protocol
setting set on the webpage.
o RAW TCP: Data sent over the network is the same as the data sent over the serial
link. Any configuration of the serial port settings will need to be set via the web page.
o Telnet + COM port Control Mode (Server): This is based on the RFC2217
standard which lets the serial ports settings be configured dynamically. Data is then
encapsulated over serial link
o Telnet
IP Settings
Device Tunnelling Setup
Device Management to:
o Restart ES device
o Restore factory settings
Security settings:
o Enable Administrator account
o MAC Address restriction
o Enable user account
