20. Technical Specifications
Device specification
Network connection
10Base-T or 100Base-TX Ethernet connection
Standard 8P8C (“RJ45”) socket connector
TCP/IP protocol stack
DHCP or static IP address
Automatic transmit/receive crossover detection
1500V isolation
RS-232 Serial Port
Baud rates up to 1M Baud
5, 6, 7 or 8 data bits
1 or 2 stop bits
Odd, even, mark, space or no parity bit
Line-break generation and detection
RTS/CTS, DTR/DSR or XON/XOFF flow control option (terminal block models do not support
DTR/DSR)
ESD protection to 15kV human body model
Can be connected to as a Windows COM port, as a raw TCP socket, or using the RFC2217 standard
Serial cable length: 3m maximum (EU only)
RS-422/485 Serial Port
Baud rates up to 1M Baud
5, 6, 7 or 8 data bits
1 or 2 stop bits
Odd, even, mark, space or no parity bit
Line-break generation and detection
RTS/CTS and XON/XOFF flow control option (terminal block models do not support RTS/CTS)
Automatic switching between transmit and receive states in half-duplex mode
3-wire half-duplex RS-422/485 link mode
Built-in termination and biasing at receiver inputs
Can be connected to as a Windows COM port, as a raw TCP socket, or using the RFC2217 standard
Serial cable length: 3m maximum (EU only)
Power
Wide-range 5-30V DC power input (1.0W typical, 1.8W maximum)
Reverse voltage protected
ESD and surge protected
Earthing connection point
ES Device Recommended Power Supply
ES-246 Shipped as standard with PW-844 (UK) / PW-811 (EU) (5V, 550mA)
ES-257 Shipped as standard with PW-844 (UK) / PW-811 (EU) (5V, 550mA)
ES-313 Shipped as standard with PW-844 (UK) PW-811 (EU) (5V, 550mA)
ES-320 Shipped as standard with PW-844 (UK) / PW-811 (EU) (5V, 550mA)
ES-357 Optional PW-644 (UK) / PW-611 (EU) (5V, 550mA)
ES-020 Optional PW-644 (UK) / PW-611 (EU) (5V, 550mA)
Caution - Do not attempt to operate this product with
any other power supply/rating than that specified.
