Brainchild P91 User Manual

25
150
250
450
650
1
1
2
2
33
4
4
5
5
1
1
22
33
44
55
66
77
88
99
10
10
11 11
END
Event 1
Event 2
Alarm 3(End
of profile)
PID 2
Time(minute)
Figure 4.7 Profiling curve example
Figure 4.7 Profiling curve example
0
12
12
Set point
0
In order to meet the response of profiling curve example. you can make a
series of setting of parameters as follow:
Global Data
Global Data
STAR = STSP
END = OFF
DLAY = 0
PFR = PV
HBT = 1.00
Profile Data
Profile Data
PROF = 1
HBBD = 50
STSP = 25.0
RMPU = HH.MM
DLLU = HH.MM
SGNO = 0
SGTY = RAMP
TGSP = 150.0
RTRR = 15
P2EV = 0000
HBTY = 1
SGNO = 1
SGTY = DLL
P2EV = 0000
HBTY = 3
DLLT = 20
Segment Data
Segment Data
Segment 0
Segment 1
UM0P411A
75
100
