BRANSON K SERIES
Carry out inspection or main-
tenance after the engine if ful-
ly cooled down.
[Otherwise]
There is a risk of getting burnt.
•
CAUTION
AIR COMPRESSOR BELT
1
LXN5O725A
Check if belt is sagging for about
0.39~0.6 in (10~15 mm) or check for
any damage to the belt by opening
bonnet and engine side cover and
pressing the middle of fan belt.
When it is not sagging enough, ad-
just tension by using adjusting bolt at
the front of compressor.
Change the belt when tension can-
not be adjusted even when the bolt
is tightened as much as possible.
Carry out inspection or main-
tenance after the engine if ful-
ly cooled down.
[Otherwise]
There is a risk of getting burnt
•
CAUTION
(1) Air Compressor Belt
