LOW BEAM/HIGH BEAM LAMP
With the main switch in the “ON” po-
sition, turn the light switch one click
to the right for low-beam and pull it
up for high-beam.
(1) Low Beam Lamp
(2) High Beam Lamp
BRAKE PEDAL CONNECTION
Brake pedals connection lamp will
light up when left and right xed con-
nection plate of brake is released.
(1) Brake Pedal Connection
AUTO PTO LAMP
AUTO PTO indicator lamp will light
up when PTO auto switch on control
panel is turned on.
(1) Auto PTO Lamp
