ENGINE OIL PRESSURE LAMP
Lamp will come on when the ignition
switch is put into the “ON” position.It
will turn off when the engine is started.
If this lamp comes on while the en-
gine is running, it indicates a problem
in the engine oil system. Stop the en-
gine immediately and check for prob-
lems.
(1) Engine Oil Pressure Lamp
LXN5O420a
BATTERY CHARGING LAMP
It will be turned on when the key
switch is put into the “ON” position,
and will be turned off when the battery
starts being charged after engine is
started and the engine revolution in-
creases. The battery will not be
charged with the engine below 1,000
rpm. (The rpm should be 1,500 rpm
or higher)
(1) Battery Charge Lamp
LXN5O422a
(1) Fuel Empty Lamp
FUEL EMPTY LAMP
It will light up when there is little fuel
in fuel tank.
Refuel immediately as empty fuel tank
may cause inhalation of air.
