Use the lifting eye (A) on the pump housing to lift and move the
hose pump.
The complete hose pump (the pumphead, gearbox and electric
motor) must be lifted using the lifting eye plus additional
support using suitably rated straps or slings (A).
5.5 Placing the pump
Do not use holes (B) when the pump is placed on the leveling elements. This
can cause the pump to tilt.
Do not use the holes in the pump supports to lift the hose pump.
The pump can be fixed to the floor using anchors. Alternatively the pump can be placed on the floor
using levelling elements.
m-bredel-25-32-en-05 31
