2. Fit the hose (A) via one of the ports.
3. Run the motor so that the rotor pulls the hose into the pump housing. Stop the motor when
the hose sticks out equally from both sides of the pump housing.
WARNING
During jogging the drive:
• Do not stand in front of the pump ports.
• Do not try to guide the hose by hand.
4. First fit the inlet port. Check the sealing ring (A) is not damaged and replace it if necessary. Fit
the sealing ring.
m-bredel-25-32-en-05 51
