8.5 Changing lubricant
Note: The drain plug is in the cover of the pump.
1. Place a tray (A) under the drain plug. The tray must be large enough to contain the lubricant,
possibly contaminated with product fluid, from the pumphead. Remove the drain plug (B).
Collect the lubricant from the pump housing in the tray.
2. Position the drain plug and tighten it to the specified torque.
3. The pump housing can be filled with lubricant via the breather (A). For this purpose remove the
breather cap (B) and position a funnel (C) in the breather. In order to facilitate the filling, the
plug (B) on the rear of the pump housing can be removed. Pour the lubricant into the pump
housing through the funnel.
m-bredel-25-32-en-05 45
