Bredel 25 - Changing Oil in the Gearbox


BA
9. Fully tighten the retaining bolts (A) of the flange bracket (B). Make sure that the bolts are
tightened to the specified torque.
AB
10. Position the hose clamp (A) against the O-ring chamber of the flange bracket (B) and fasten the
retaining bolt.
11. Now fit the other port. For this port proceed in the same way as described above for the inlet
port.
12. Fill the pump housing with Bredel Genuine Hose Lubricant.
