Bredel 25 - Fluid Leakage

A
B
6. Loosen the retaining bolts (A) of both the suction and discharge line (B). Disconnect the suction
and discharge lines.
BA
7. Loosen the hose clamp (A) of both the inlet and outlet ports by loosening the retaining bolt (B).
B
A
8. Pull the insert (B) from the hose and remove the flanges (A). Carry out this procedure both for
the inlet and outlet ports.
m-bredel-25-32-en-05 47
