Function
Location
Zone Lights or Status
Light flash frequency
Buzzer alert
Interval
System off
(not powered or
Configuration Tool
in connected state
BS-8000 only)
Status Light
off
off
System power on
Self Test
(after applying
power supply)
all Zone Lights
constant for 1 second
constant for
1 seconds
Status Light
red / constant for
5 seconds
System Standby
(after Self Test)
Status Light
red / constant
off
System Active and
no object detection
(via Activation Input)
Status Light
green / constant
off
Detection in Zone 5
(Furthest Detection
Zone)
Green Zone Light
constant
1.5 times per
second
Detection in Zone 4
Green & Light Green Zone
Lights
constant
2 times per
second
Detection in Zone 3
Green & Light Green & Yellow
Zone Lights
constant
2.5 times per
second
Detection in Zone 2
Green & Light Green & Yellow
& Orange Zone Lights
constant
3 times per
second
Detection in Zone 1
(Closest Detection
Zone)
Green & Light Green & Yellow
and Orange & Red Zone Lights
constant
constant
System Error
occurred with
System Active
all Zone Lights
constant for 5 seconds
constant for
5 seconds
Status Light
red / 1 time per second
System Error with
System Active
Status Light
red / 1 time per second
0.5 seconds,
repeated in
5 seconds
System Error with
System Standby
Status Light
red / 1 time per second
off
BS-7030, 7045 & 7060 each has a fixed detection length and width. The length is divided into
five equal detection zones. The buzzer and trigger output activate in all zones on detection.
BS-8000 uses the same fundamental operation as all the above systems but the settings are
fully configurable: Detection length, detection width, zones length, blind length, blind width and
blind zones, trigger output length and buzzer starting zone. Refer to section “4 Configurable
System Model BS-8000”.
3.7 Initial System Power Up and Test
Once the sensor and display are installed and connected, power should be applied to test
correct system operation. On power up, the display will go through its self-test by sounding the
buzzer and illuminating the Status Light red and all Zone Lights. After about 5 seconds only
the Status Light should show red colour. When the activation input becomes active (e.g.
reverse gear is selected to apply power to the activation input) the status light turns green and
the system is in detection mode. Check the system is operating correctly in an open area with
no obstructions.
