Brigade Backsense BS-7030 - 6 Specifications

34
6 Specifications
Operation Characteristics
Detection range
5 zones in equal (fixed range systems) or configurable lengths
Model name
BS-8000
BS-7030
BS-7045
BS-7060
Type
Configurable (* Default Setting)
Fixed Range
[m]
[ft]
[m]
[ft]
[m]
[ft]
[m]
[ft]
Detection length
3 - 30 (10)*
10 - 98 (33)*
3
10
4.5
15
6
20
Each Detection Zone length
1 - 26 (2)*
3 - 85 (7)*
0.6
2
0.9
3
1.2
4
Detection width
2 - 10 (7)*
7 - 33 (23)*
2.5
8
3.5
12
4.5
15
Nominal tolerance
±0.25m / 1ft
Radar beam angle
Horizontal 120° out to the maximum designated width
Vertical 12°
(symmetrically perpendicular to sensor front surface)
Distance resolution
≥ 0.25m (1ft) (limitations apply, see section “1.2 Object
Detection Capability”)
Object detection
≤ 0.5second (limitations apply, see section “1.2 Object
Detection Capability”)
Power on to system ready
≤ 6 seconds
System standby to active
≤ 0.2 second
Communication between Sensor and Display
Physical layer
CAN bus
Protocol layer
Proprietary Protocol (cannot be integrated or networked with
other systems on vehicles)
Max. cable length between
display and sensor
30m (98ft)
Sensor Specifications
Transmitter
Frequency Modulated Continuous Wave (FMCW)
Frequency and bandwidth
24.068GHz to 24.218GHz
Dimensions (all in mm)
217 x 129 x 50
Connector
Manufacturer Deutsch
Part Number DT06-4S-CE06
Cable length
1.0m / 3ft 3in
Weight
0.7kg (including pigtail cable)
Operating temperature
-40°C to +85°C
IP protection
IP69K (protected from dust and strong water jets / immersion
into water) protective housing
Vibration
20G
Shock
100G all three axes
Mounting
Four (5.2mm) diameter holes on 198mm horizontal centres,
and 40mm vertical centres.
Unit is supplied with M5x30mm screws and M5 polymer
locknuts for mounting purposes. Recommended torque is 50
inch/lbs
Bracket
Optional, adjustable for vertical angle
