Brigade Backsense BS-7030 - Page 35

35
Display Specification
Zone Lights
Large and high ambient light visibility
Luminance >300cd/m
2
Buzzer
Buzzer volume control wheel
Sound pressure level adjustable 65dB(A) to 90dB(A) (at 1m
distance), frequency 2800±300Hz
Programming interface
Mini USB socket (configurable version only)
Dimensions (all in mm)
101 x 70 x 29 (with bracket 71)
Connector
Manufacturer Deutsch
Part Number DT04-4P-CE02
Cable length
1.5m / 5ft
Weight
0.3kg (including pigtail cable)
Operating temperature
-40°C to +85°C
IP Protection
IP30 (not water protected)
Vibration
20G
Shock
100G all three axes
Mounting
Via bracket adjustable in all direction approximate 30°
Base supplied with self-adhesive tape. Possibility to fix base
with additional screws (not supplied, drilling required)
Removable bracket for flush mount
Electrical Specification
Input voltage
9Vdc to 32Vdc
Input current
typ. 0.62A at 12Vdc / typ. 0.32A at 24Vdc / max. <0.8A
Fuse
3A, automotive (regular size) blade fuse type, located on red
power supply cable
Polarity
Negative ground
Vehicle connection
System supply positive, negative, activation input and trigger
output
4 single cables exiting at the back of the connector on the
end of the display cable
Activation Input:
Rating 0Vdc to 32Vdc
System active above 9Vdc, inactive below 7Vdc
Trigger Output
Active State: switched to ground up to 0.5A
Inactive State: High impedance (> 1 MOhm)
Voltage protection
ISO 7637 (over and reverse voltage protection)
Approvals
CE
ECE Regulation No. 10 Revision 4 (“E-marking”)
ISO 16750
ISO 13766
EN 13309
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Any change or modifications not expressly approved by the responsible party responsible for compliance could void the user’s
authority to operate the equipment.
Brigade Electronics
BS-7030 / BS-7045 /
BS-7060 / BS-8000 /
BS-XXXX
