24 Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 Revision D

Installer maintenance includes cleaning the heat exchanger

DQG IDQ 'HSHQGHQWRQ WKHFRQGLWLRQV WKLVPXVW GRQH DERXW

once every three years.

1 Take the voltage from the appliance.

 2SHQWKH¿OWHUGRRU

 5HPRYHWKH¿OWHU

3 8QVFUHZWKHIURQWSDQHOZLWKWKHWZR¿OWHUGRRUVVFUHZV

and take it out.

4 Unscrew the 8 screws that hold the fan compartment pa-

nel.

5 Carefully tilt the fan panel forward; take the fan cables from

the cable clips so the panel can be opened further.

6 Take the two fan cables from the pcb.

&KDSWHU0DLQWHQDQFH

9.2 Maintenance

4 x

Torx T20

2 x

T20 x 25 mm

6 x

T20 x 10 mm

X10 X11
