Brivo ACS6100 Installation Manual
Switch Setting Description Functionality Description
SW 7-1 Tamper
Enabled: Tamper functionality is in use
Disabled: Tamper functionality is not in use
SW 7-2 CAN Bus
Enabled: CAN Bus is terminated
Disabled: CAN Bus is not terminated
SW 7-3
SW 7-4 Maintenance Mode
For general operation, SW 7-4 needs to be in
the O position.
SW 7-5
SW 7-6 Factory Reset
How to perform factory reset:
• Ensure that SW 7-6 is in the OFF
position.
• Power o MAIN CONTROL BOARD.
• Place SW 7-6 dip switch in the ON
position.
• Power on the board and wait until you
hear two two-second long beeps and
see the main heartbeat LED turn o.
• Within 10 seconds of hearing the beeps,
place SW 7-6 dip switch back into the
OFF position.
• You will hear a one second-long beep
and the main heartbeat LED will start
blinking again indicating the system is
performing a factory reset.
• After the factory reset is complete, you
will hear 2 short beeps.
• At this point, the factory reset is
complete and the system will now run
with factory default rmware.
SW 7-7 Diagnostic
Enabled: MCU Full Debug
Disabled: MCU Standard Debug
SW 7-8 Wi-Fi
Enabled: Wi-Fi can be used if congured
Disabled: Wi-Fi cannot be used at all, even if
congured
