Brocade DCX 8510-8 Backbone Hardware Reference Manual 51
53-1002180-03
Determining the status of a core switch blade (CR16-8)
4
Table 5 describes the CP blade LED patterns and the recommended actions for those patterns.
Determining the status of a core switch blade (CR16-8)
Complete the following steps to determine the status of a core switch blade (CR16-8).
TABLE 5 CP blade LED descriptions
LED purpose Color Status Recommended action
Power Steady green CP blade is on. No action required.
No light (LED is off) CP blade is not on. Ensure that the blade is firmly
seated and has power.
Status No light (LED is off) CP blade is either healthy
or does not have power.
Verify that the power LED is on.
Steady amber CP blade is faulty or the
switch is still booting.
Ensure that the blade is firmly
seated and the switch has
completed booting. If LED remains
yellow, consult the Brocade DCX
8510-8 supplier.
Slow-flashing amber (on 2
seconds; then off 2 seconds)
CP blade is not seated
correctly or is faulty.
Pull the blade out and reseat it. If
the LED continues to flash, replace
the blade.
Fast-flashing amber (on 1/2
second; then off 1/2 second)
Environmental range
exceeded.
Check for out-of-bounds
environmental condition and
correct it.
Ethernet Link
Status
No light (LED is off) Either an Ethernet link is
not detected, or it does not
have incoming power.
Ensure that the blade has power,
the Ethernet cable is firmly seated,
and the connected device is
functioning.
Flickering green/amber Ethernet link is healthy
and traffic is flowing
through port.
No action required.
Ethernet Link
Speed
No light (LED is off) Ethernet link speed is 10
Mb/s or CP blade does not
have incoming power.
Ensure that the CP has power.
NOTE: To force a persistent Ethernet
link speed, enter the ifModeSet
command.
Steady green Ethernet link speed is
100/1000 Mb/s.
No action required.
USB Status Lamp on USB stick enabled. No action required.
Lamp off USB stick not present or
disabled.
No action required.
Active CP Steady blue Active CP blade. No action required.
No light (LED is off) Standby CP blade. No action required.
