168 Brocade FastIron X Series Chassis Hardware Installation Guide
53-1001723-02
Chassis specifications
7
Cable specifications
Table 32 lists the specifications for the cables used with the 10/100, Gigabit, and 10-Gigabit
Ethernet ports.
NOTE
Cable installation and network configuration will affect overall transmission capability. The numbers
provided below represent the accepted recommendations of the various standards. For
network-specific recommendations, consult your local Brocade reseller or system engineer.
TABLE 32 Cable length summary table
Cable Type
1
Connector Type Core Diameter
(microns)
Modal
Bandwidth
(MHz*km) or
Wavelength (nm)
Range (meters)
1000Base-BX-D Single-mode
Fiber (SMF)
LC connector for
SFP module
9 1490 nm 2 – 10000
(10km)
1000Base-BX-U SMF LC connector for
SFP module
9 1310 nm 2 – 10000
(10km)
1000Base-LHA SMF LC connector for
SFP module
9 1550 nm 2 – 70000
(70km)
1000Base-LHB SMF LC connector for
SFP module
9 1550 nm 2 – 120000
(120km)
1000Base-LX Multi-mode
Fiber (MMF)
LC connector for
SFP module
62.5 500 2 – 550
MMF 50 400 2 – 550
MMF 50 500 2 – 550
SMF 9 1300 nm 2 – 10000
1000Base-SX MMF LC connector for
SFP module
62.5/125 200 .5 – 275
MMF 62.5/125 500 .5 – 550
MMF 50/125 900 .5 – 595
MMF 50/125 1500 .5 – 740
MMF 50/125 2000 .5 – 860
1000Base-SX 2 MMF LC connector for
SFP module
62.5 500 up to 2000 (2
km)
1000Base-T Copper RJ-45 jack for
standard
unshielded
twisted pair
(UTP or Category
5)
n/a n/a up to 100
meters
100Base-BX SMF LC connector for
SFP module
9 1310/1490 10000 (10
km)
100Base-FX-SR MMF LC connector for
SFP module
62.5 500 up to 2000 (2
km)
100Base-FX-IR SMF LC connector for
SFP module
9 1310 up to 15000
(15 km)
