Hardware features
1
Figure 6 also shows an electrostatic discharge (ESD) connector, into which you can plug an ESD
wrist strap to ground yourself while handling and installing modules.
For safety reasons, the ESD wrist strap should contain a series 1 meg ohm resistor.
FSX 1600-ANR chassis
This section describes the differences between the FSX 1600-ANR chassis and the FSX 1600
chassis. For details about the similarities, refer to “FSX 1600-ANR chassis” on page 12.
The FSX 1600 Acoustic Noise-Reduced (ANR) chassis is an enhanced version of the FSX 1600
chassis. Part numbers for the FSX 1600-ANR chassis and bundles begin with FI-SX-1600-ANR-xxx
Except where explicitly noted throughout this manual, the FSX 1600 and FSX 1600-ANR chassis are
collectively referred to as the FSX 1600 chassis.
If you want to upgrade your existing FSX 1600 to an FSX 1600-ANR chassis, you must ship it to
Brocade, where an ANR kit will be installed, then the chassis will be shipped back to you. For more
information, contact Brocade
8Interface slot 8
9 Management slot 9
10 Management slot 10
11 Interface slot 11
12 Interface slot 12
13 Interface slot 13
14 Interface slot 14
15 Interface slot 15
16 Interface slot 16
17 Interface slot 17
18 Interface slot 18
19 Switch fabric slot 1
20 Switch fabric slot 2
21 ESD connector
