Brocade FastIron X Series Chassis Hardware Installation Guide 169
53-1001723-02
Chassis specifications
7
Power cords
All of the FastIron devices ship with US-compatible power cords unless otherwise specified at the
time of order. United Kingdom- and European-compatible power cords are also available.
Refer to “Input connector and plug” on page 172.
100Base-FX-LR SMF LC connector for
SFP module
9 1310 up to 40000
(40 km)
100Base-TX Copper RJ-45 jack for
standard
unshielded
twisted pair
(UTP or Category
5)
n/a n/a up to 100
meters
10GBase-1310 MMF LC connector for
XFP module
9 1310 nm up to 200
meters
10GBase-CX4 Copper CX4 connector
for XFP module
n/a n/a up to 15
meters
10GBase-ER SMF LC connector for
XFP module
9 1550 nm up to 40000
(40 km)
10GBase-LR SMF LC connector for
XFP module
9 1310 nm 2 – 10000
(10km)
10GBase-SR MMF LC connector for
XFP module
62.5/125 160 2 – 26
62.5/125 200 2 – 33
50/125 400 2 – 66
50/125 500 2 – 82
50/125 2000 2 – 300
10GBase-ZR SMF LC connector for
XFP module
9 1550 nm up to 80000
(80 km)
10GBase-ZRD SMF LC connector for
XFP module
9 1530.33 –
1561.42 nm
up to 80000
(80 km)
1. SMF = Single Mode Fiber, MMF = Multi-Mode Fiber
TABLE 32 Cable length summary table (Continued)
Cable Type
1
Connector Type Core Diameter
(microns)
Modal
Bandwidth
(MHz*km) or
Wavelength (nm)
Range (meters)
