Brocade FastIron X Series Chassis Hardware Installation Guide 31
53-1001723-02
Hardware features
1
• Ports 1 – 12
• Ports 13 – 24
• 24-port Gigabit Ethernet Fiber Interface Module:
• Ports 1 – 12
• Ports 13 – 24
• 2-port 10-Gigabit Ethernet Fiber Interface Module
• Port 1
• Port 2
Power supplies
The FastIron X Series chassis ships with one or two power supplies, depending on how it was
ordered from the factory.
• The FSX comes with one AC or DC power supply. You can install up to four power supplies in the
FSX chassis.
• The FSX 800 comes with one 12-volt AC power supply. You can install up to four power supplies
in the FSX 800 chassis.
• The FSX 1600 comes with two12-volt AC power supplies. You can install up to eight power
supplies in the FSX 1600 chassis; four 12-volt AC or DC supplies and four 48-volt AC power
supplies for POE.
You can use any combination of the supported AC and DC supplies in the same device.
NOTE
Note the following regarding POE power supplies:
• The SX-ACPWR2500-POE requires 220-volt input.
• The SX-ACPWR2500-POE powers up to 140 class 3 POE ports, therefore, the SX-ACPWR-POE is
not sufficient as a backup power supply.
The following table lists the power supplies supported in the FastIron X Series chassis devices.
Sales Model Number Description
1
FSX FSX 800 FSX 1600
SX-ACPWR-SYS 12-volt AC replacement
power supply,
manufacturing part
number 32014-xxx
2
Supported Supported Supported
12-volt AC original power
supply, manufacturing
part number 30351-xxx
2
Supported Supported Supported
SX-ACPWR-POE 48-volt AC replacement
power supply,
manufacturing part
number 32016-xxx
2
Supported Supported Supported
48-volt AC original power
supply, manufacturing
part number 30352-xxx
2
Supported Supported Supported
SX-DCPWR-SYS 12-volt DC Supported Supported Supported
