Brocade FastIron X Series Chassis Hardware Installation Guide 65
53-1001723-02
Verifying proper operation
2
Interface Module
Link or
Activity
On or blinking A link is established with
the remote port and the
port is transmitting and
receiving user packets.
Off At this stage of the installation,
you have not yet cabled the
Gigabit Ethernet ports, so this
LED will be off.
After cabling this port, if this
LED is off, a link is not
established with the remote
port.
POE (if
applicable)
On – Green The port is enabled, a
power-consuming device
has been detected, and
the module is supplying
power to the device.
Off The port is not providing in-line
power.
AC and DC Power Supplies
AC OK (AC
supply only)
ON – Green (steady) The power supply is
receiving AC power from
an AC power source
OFF The power supply is not
receiving power from an AC
power source. You can do the
following:
• Make sure that the power
supply cord is connected
securely to the wall outlet
and the power supply.
• Make sure that the wall
outlet is rated for 115 or
120V and 20A. If it is not,
obtain a cable that is
compatibly rated for the
outlet.
• Make sure that the wall
outlet has power.
DC IN (DC
supply only)
Green (steady) The power supply is
receiving DC power from a
DC power source
OFF The power supply is not
receiving power from a DC
power source. You can do the
following:
• Make sure that the power
supply cables are
connected securely to the
power source and the
power supply.
• Make sure that the DC
power source is 48VDC @
30 A.
• Make sure that the power
source has power.
TABLE 17 Desired and abnormal LED states after system power on (Continued)
LED Desired State Meaning Abnormal
State
Meaning or Action
