AC power supply specifications
All devices ship with one removable AC power supply unit with a standard IEC type (IEC320) input
connector, operating 100 VAC to 240 VAC input, universal or wide input.
NOTE
For HPOE+ Class 4 power usage, FCX devices with two power supplies can only support up to 27
HPOE ports. For Class 1, 2, or 3 power usage, these devices can support up to 48 ports.
AC power supply specifications TABLE 30
Input voltage
range
Input current(PSU x
1)
Inrush current Power draw Max output
power (PSU
x1)
Brocade FCX
624S
100 - 240 VAC 1.2 - 2.8 Amps < 75 Amps peak
maximum
94 W 210 W
Brocade FCX
648S
100 - 240 VAC 1.2 - 2.8 Amps < 75 Amps peak
maximum
122 W 210 W
Brocade FCX
624S-HPOE
100 - 240 VAC 3.3 - 7.8 Amps < 75 Amps peak
maximum
107 W509 W with
HPOE509 W with
HPOE+
620 W
Brocade FCX
648S-HPOE
100 - 240 VAC 3.3 - 7.8 Amps < 75 Amps peak
maximum
167 W970 W with
HPOE970 W with
HPOE+
620 W
Brocade FCX
624S-F
100 - 240 VAC 1.2 - 2.8 Amps < 75 Amps peak
maximum
102.1 W 210 W
Brocade FCX
624-E
100 - 240 VAC 1.2 - 2.8 Amps < 75 Amps peak
maximum
92 W 210 W
Brocade FCX
624-I
100 - 240 VAC 1.2 - 2.8 Amps < 75 Amps peak
maximum
92 W 210 W
Brocade FCX
648-E
100 - 240 VAC 1.2 - 2.8 Amps < 75 Amps peak
maximum
112 W 210 W
Brocade FCX
648S
100 - 240 VAC 1.2 - 2.8 Amps < 75 Amps peak
maximum
112 W 210 W
AC power supply specifications
Brocade FCX Series Hardware Installation Guide 93
53-1002977-01
