Reset button
The reset button allows you to restart the system without switching the power supplies o and on or using the CLI. When the reset button
is pressed, the system resets and the software is reloaded. The button is directly below the power LED on the left of the front panel.
Network interfaces for an ICX-6430-C device
An ICX 6430-C device contains the following interfaces:
12 1-GbE ports with RJ-45 copper connectors (Slot 1, Ports 1-12)
Ports 1- 4 are dedicated PoE/PoE+ ports.
Standard 802.3at PoE+ ports support up to 30W per port.
Standard 802.3af PoE ports support up to 15.4W per port.
Total PoE power capacity is 68W.
Some possible PoE/PoE+ conguration combinations include:
2 standard PoE ports supporting full capacity (15.4W x 2 = 30.8W)
1 standard PoE+port supporting full capacity (30W)
1 PoE or PoE+ port supporting partial capacity, no greater than 7W (7W)
Total PoE/PoE+ power: 67.8W
2 standard PoE+ ports supporting full capacity (30W x 2 = 60W)
1 PoE or PoE+ port supporting partial capacity, no greater than 7W (7W)
Total PoE/PoE+ power: 67W
4 standard PoE ports supporting full capacity (15.4W x 4 = 62W)
Total PoE power: 62W
4 100 Mbps/1 GbE uplink ports:
2 100 Mbps/1 GbE RJ-45 uplink ports (Slot 2, ports C1-C2)
2 100 Mbps/1 GbE SFP uplink ports (Slot 3, ports F1-F2)
Slot designations
The following table lists the slot designations for an ICX 6430-C device. Refer to the “Network and management interfaces” section for
the location of slots 1- 3 on the front panel of an ICX 6430-C device.
TABLE 1 Slot designations for an ICX 6430-C device
Device Slot 1 (1 GbE RJ-45 ports) Slot 2 (100 Mbps/1 GbE RJ-45
ports)
Slot 3 (100 Mbps/1 GbE SFP
ports)
ICX 6430-C12 Ports 1-12 Ports C1- C2 Ports F1-F2
1 GbE RJ-45
An ICX t6430-C device provides 12 RJ-45 ports that reside on Slot 1 of the device. The 12 RJ-45 ports operate at 10 Mbps or 100
Mbps half or full duplex, or at 1000 Mbps full duplex. Because all ports support automatic MDI or MDI-X operation, you can use
straight-through cables for all network connections to PCs or servers, or to other devices or hubs. In addition, it is ideal (and preferred) to
use straight-through cables for switch-to-switch connections.
Network and management interfaces
Brocade ICX 6430-C Compact Switch Hardware Installation Guide
12 Part Number: 53-1003618-02
