Managing an ICX 6430-C Device
• Temperature settings........................................................................................................................................................................................43
Temperature settings
The device contains temperature sensors that the software reads based on a congurable device poll time. The device has two automatic
speed fan control settings based on the temperature. To protect the device from overheating, the following temperature threshold levels
exist:
• The warning level is the temperature at which the device generates a syslog message. It is congurable up to the shutdown
temperature.
• The shutdown level is the temperature at which the device reboots. It is set by the device and is not congurable. When the
device temperature reaches the shutdown level, it generates a warning message that the device’s temperature is over the
shutdown level and the device shuts down in 5 minutes. The system restarts 5 minutes after the device reaches the
temperature shutdown level.
NOTE
The shutdown temp is xed for each model. You can change the warning temperature, but its maximum value cannot be
greater than the shutdown temperature minus 3°C.
The following ate the temperature thresholds for ICX 6430-C12 devices.
Model Warning level temperature threshold
(°C)
Critical (shutdown) temperature threshold
(°C)
ICX 6430-C12 You cannot set the warning level temperature
higher than 80°C.
83°C
Displaying the temperature
To display the temperature of a device, enter the show chassis command at any level of the CLI. The show chassis command displays
the power supply status, and temperature threshold levels for fan speed.
NOTE
The displayed temperature reects the temperature of the board inside the
device.
device# show chassis
The stack unit 1 chassis info:
Power supply present, status ok
Fanless model
Sensor B Temperature Readings:
Current temperature : 55.0 deg-C
Sensor A Temperature Readings:
Current temperature : 50.0 deg-C
Warning level.......: 76.0 deg-C
Shutdown level......: 83.0 deg-C
Boot Prom MAC : 748e.f8ea.0360
Management MAC: 748e.f8ea.0360
=====
Syntax: show chassis
Brocade ICX 6430-C Compact Switch Hardware Installation Guide
Part Number: 53-1003618-02 43
