Brocade Communications Systems ICX 6430-C Hardware Installation Guide

System component Description
Link/Act (100 Mbps/1 GbE SFP
ports)
Indicates whether a link is established with a remote port and the SFP port is operating at 1 Gbps.
System status LEDs
PWR (Power) Indicates whether power supply is operating normally.
Diag (Diagnostic) Indicates the status of the system self-diagnostic test.
Uplink Reserved for future use.
Downlink Reserved for future use.
ID Reserved for future use.
Network connection status LEDs
Link/Act (Ethernet) Indicates whether a link is established with a remote port and the port is operating normally.
PoE/PoE+ Indicates whether the port is providing PoE or PoE+ power to a connected device.
Link/Act (uplink ports) Indicates whether a link is established with a remote port and the uplink port is operating normally.
Link/Act (SFP ports) Indicates whether a link is established with a remote port and the SFP port is operating normally.
Other
System component Description
Serial cable RJ-45 serial
RJ-45 connector 100 Mbps/1 Gbps SFP ports for uplink: FX, SX, LX, TX, LHA, LHB; 10/100/1000 Mbps RJ-45 ports for
uplink
Weight and physical dimensions
Model Height Width Depth Weight
ICX 6430-C12 4.3 cm
1.7 in.
26.9 cm
10.6 in.
21.3 cm
8.4 in.
1.9 kg
4.2 lb
Environmental requirements
Condition Operational Non-operational
Ambient temperature 0°C to 40°C (32°F to 104°F) -40°C to 70°C (-40°F to 158°F)
Relative humidity (non-
condensing)
5% to 95% 0% to 95%
Altitude (above sea level) 3000 m (10,000 feet) 4572 m (15,000 feet)
Heat dissipation 62 BTU/hr N/A
Other
Brocade ICX 6430-C Compact Switch Hardware Installation Guide
46 Part Number: 53-1003618-02
