1-6
Engine:
Standard Gasoline:
Kubota 1.6L, EFI Dual Fuel, EPA Tier 2 Certified:
Kubota WG1605-GL-E3 gasoline engine complete with multi-port electronic fuel
injection, dual fuel, and engine management system. Water-cooled, 4-cylinder,
94 CID (1.6 L), 3.11-inch (79 mm) bore, 3.09-inch (78.4 mm) stroke, 57.0 HP
(32.6 kW) at governed speed of 2600 rpm. Maximum torque, 88.7 ft-lbs (120.2
Nm) at 2400 RPM. 70-amp alternator, 13.5-gallon (51 L) gas tank, and 33 lb
(15 kg) LPG tank.
Optional Engines and Accessories:
Kubota, Diesel, 1.8L, EPA Tier 4 Final Certified:
Kubota D1803-CR-TIE4B diesel engine. Water-cooled, 3-cylinder, turbocharged
and inter-cooled, 111 CID (1.8 L), 3.43-inch (87 mm) bore, 4.04-inch (102 mm)
stroke. 49.6 HP (37.0 kW) at governed speed of 2700 RPM. Maximum torque
111.0 ft-lbs (150.5 N-m) at 1600 RPM. 12V, 60-amp alternator. Net weight: 432
pounds (196 kg).
Hydrostatic Transmission Pump:
Standard:
Sauer-Danfross piston type, 2.8 CID (45 mL) per revolution, direct driven from
engine crankshaft. Maximum flow 34 GPM (129 L/min). Maximum pressure-
4000 PSI (275 bar). Electro-hydraulic servo and electronic, automotive type
controller.
Front Axle:
Standard:
Planetary drive/steer axle with an overall 16.15/1 ratio. Differential is limited
slip. Axle is rigidly mounted to frame.
Rear Axle:
Standard:
Planetary drive/steer axle with an overall 16.15/1 ratio. Differential is limited
slip. Axle oscillates 1.5° in either direction.
Steering:
Standard:
Full-hydraulic steering unit controls a steering cylinder attached to each axle.
Limited steering, if engine dies. Rear axle is the primary steer. An electric
switch in the operator’s compartment is used to select rear-wheel steering,
four-wheel round steering, or crab steering. Electronic sensors and control box
automatically align the steering when a new mode is selected.
