Section 3 – Slave Information
Brooks EtherCAT MFCs
Warning
Mask
corresponding device warning
exception bits (as defined in the
device warning details) in the active
and latched exception status
objects (0xF380 bit 0 and 0xF390
bit 0), if the corresponding bit is
TRUE.
Default of all bits TRUE (no
masking).
0xF3A2
0x01
UDINT
RW
Manufacturer
Warning
Mask
Bitmask to include the
corresponding manufacturer
warning exception bits (as defined
in the manufacturer warning details)
in the active and latched exception
status objects (0xF380 bit 1 and
0xF390 bit 1), if the corresponding
bit is TRUE.
Default of all bits TRUE (no
masking).
All
0xF3A3
0x01
UDINT
RW
Device Error
Mask
Bitmask to include the
corresponding device error
exception bits (as defined in the
device error details) in the active
and latched exception status
objects (0xF380 bit 2 and 0xF390
bit 2), if the corresponding bit is
TRUE.
Default of all bits TRUE (no
masking).
All
0xF3A4
0x01
UDINT
RW
Manufacturer
Error Mask
Bitmask to include the
corresponding manufacturer error
exception bits (as defined in the
manufacturer error details) in the
active and latched exception status
objects (0xF380 bit 3 and 0xF390
bit 3), if the corresponding bit is
TRUE. Default of all bits TRUE (no
masking).
All
3.8. Manufacturer Specific Device Data
Table 3-17 – Manufacturer Specific Device Data
Index
Sub
Index
Data Type
Access
Name
Description
Device Profile(s)
Supported
