EN | 8 About these original operating instructions // Brose Display Allround E41230
6 Explanation of illustrations
Illustrations in this user manual show
functions by way of example and may
differ from the actual appearance of your
Brose Drive System.
All illustrations are schematic and
examples only. Some details may vary
for your e-bike depending on the e-bike
manufacturer. Detailed information on
your entire e-bike is available from your
dealer and e-bike manufacturer.
The numbering in the following tables
refers to the illustrations at the beginning
of this manual.
Illustration overview
A. Quick start overview
B. Key assignment overview
C. Assembly and adjustment
Illustrated components
(1) Button (On/Off)
› Switch system on/off
(2) Button (Menu)
› Confirm selection
(3) Button (Light)
› Jump menu back one level
(4) Button (Plus)
› Increase assistance level /
› Page up menu
(5) Button (Minus)
› Decrease assistance level /
› Page down menu
› Activate push assist
(6) Button (Push Assist)
› Release push assist
(7) Plug
› Connection to the motor unit
(8) Grub screw
› Control unit fastening
